As a professional manufacturer,are always keep product Quality come first, main product including the suspended platform,construction hoist,tower crane,Auto Parking System and so on construction equipment,Weclome to visit our factory!
construction cleaning cradle is throught the top of suspension mechanism on the roof of buildings, hanging with wire rope along building facades, the motor assembly with two side of gondola and drive the load which inside the gondola up and down. work gondola have a stromg adaptability to construction site, it is always to be used for wall cleaning, maintenance, decoration, windows or other kind glasses cleaning, installation, maintenance or high buildings surface painting works.
We pay all our attention for the Construction work cradle, working construction cradle, hanging construction cradle, construction cradle design and manufacturing. Wall construction cradle for high buildings and windows cleaning A good tools and make work efficiently.
Technical parameters of construction cleaning cradle:
|fabrication material||steel/aluminum alloy|
|steel rope angle adjusting range||3°-8°||3°-8°||3°-8°||3°-8°|
|distance between two steel rope||≤100mm||≤100m||≤100m||≤100m|
|diameter of steel rope||8.3mm||8.3mm||9.1mm||10.2mm|
|max lifting height(m)||300m||300m||300m||300m|
|motor rotation speed||1420r/min||1420r/min||1420r/min||1420r/min|
|voltage(3phases)(optional)||220v/380v/415v/440v 50hz/60hz to be OEM|
Main Parts of construction cleaning cradle:
|1. construction cradle(basket): Steel or Aluminum Alloy (painted or hot galvanized)||6. Steel wire rope: 8.3mm ,8.6mm or 9.1mm|
|2. Suspension Mechanism: Steel (painted or hot galvanized)||7. Safety rope: 18mm,20mm|
|3. Electric hoists:LTD6.3 or LTD8||8. Electric cable: 3*2.5+2*1.5|
|4. Safety Lock: LST30||9. Counterweights: Cement , cement with steel cover & Iron counterweight|
|5. Electric control box: Along with hoists||10. Spare parts|
Packing and Shipping
Packages Details of construction cleaning cradle for high buildings and windows cleaning
|package||platform||counter weight||hoist & safety lock||control panel & other smallparts|
|film||pallet||wooden case||carton box|
The suspended construction cradle can be customized according to customers'requirements(drawing, specifications and so on).
Good quality is assured by advanced manufacturing technology.and all products will be checked by our quality-control manager.
We provide standard,strong,protective package for our products to prevent is from outer damage.
Detailed information,specific model and price of price of products will be provided quickly after receiving your inquiry.
Welcome to visit our factory!
Any questions,Please feel free to contact me!
